Tabung Kaca Kuarsa Bening Stabil Termal Tanpa Gelembung Udara dan Transmisi Cahaya Tinggi
Detail Produk
| Bahan: | SiO2> 99,99% | OD: | 3-300mm |
|---|---|---|---|
| Transmisi Cahaya: | > 92% | Temparature bekerja: | 1100 ℃ |
| Kekerasan: | Musa 6.5 | Nilai Resistansi: | 1000 kali lipat dari kaca biasa |
| Menyoroti |
Tabung kaca kuarsa warna bening,batang tabung kaca kuarsa menyatu,tidak ada gelembung udara batang tabung kuarsa |
||
Deskripsi Produk
| Tipe | JGS1 (ZS-1) | JGS2 (ZS-2) | JGS3 (HS) |
|---|---|---|---|
| Karakteristik Spektral | 180-2500nm | 200-2500nm | 260-3500nm |
| Transmisi Rata-rata | 90% | 85% | 85% |
| Kelas Gelembung | 0 | 2 | 2 |
| Birefringence | 1-2 | 1-2 | 1-2 |
| Struktur Biji | 1 | 2 | 2 |
| Garis | 1-2 | 2 | 2 |
| Keseragaman | 1-2 | 2 | 2 |
| Fluoresensi | 1 | 2 | 2 |
| Kinerja Radiasi | Tidak berubah warna | Sedikit perubahan warna | Berubah warna |
- Kemurnian tinggi: SiO₂ > 99,99%
- Kinerja visual dan kimia yang sangat baik: tahan asam, tahan alkali
- Stabilitas termal yang baik dan perlindungan lingkungan perawatan kesehatan
- Tidak ada gelembung udara dan tidak ada garis udara
- Sifat isolator listrik yang sangat baik
| SiO₂ | 99,9% |
| Kepadatan | 2,2 g/cm³ |
| Tingkat Kekerasan (Skala Moh) | 6,6 |
| Titik Leleh | 1732℃ |
| Suhu Kerja | 1100℃ |
| Suhu Jangka Pendek Maks | 1450℃ |
| Transmisi Cahaya Tampak | Di atas 93% |
| Transmisi Wilayah Spektral UV | 80% |
| Titik Anil | 1180℃ |
| Titik Pelunakan | 1630℃ |
| Titik Regangan | 1100℃ |
LIANYUNGANG SHENGFAN QUARTZ PRODUCTS CO.LTD
WhatsApp: 008617696882108
Email: amy@quartzglassproducts.com
Alamat: NO.169 Mingzhu Rd, Economic Development Zone, Donghai country, Lianyungang city, Jiangsu prov., China.
Sorotan Produk
Tabung Kaca Kuarsa Bening Warna Jernih Tabung kaca kuarsa silika bening yang stabil secara termal, diproduksi dari pasir kuarsa dengan kemurnian tinggi. Menampilkan stabilitas kejut termal yang sangat baik dan transmisi tinggi untuk aplikasi dalam pencahayaan listrik, sistem laser, lensa, instrumen ...
XRD Sampel Tangki Uji Lembar Pembawa Chip Tangki Tangki Kaca Kuarsa Lembar Contoh Dapat Disesuaikan
Thin Quartz Glass Plate Dimensional Stable 1-1000mm Processing Range Product description: Fused clear silica quartz glass plate is made of high purity quartz sand with excellent thermal shock stability and high transmittance. It is widely used in electric light/ laser/ lenses/optical instrument/high temperature window. Specification Quick Details Place of Origin Jiangsu,China Brand SF Material Glass,High quality Optical Glass Usage Optical Structure Double Convex Shape
Photocatalytic Reactor Kimia Kit Glassware
Product description: 1.SiO2> 99.99% ,tubing fused quartz 2.Operating Temperature: 1250℃ 3.Excellent visual and chemical performance . 4.Without surface coating andinfectant . 5.Health care and environmental protection. 6.Any specification can be made. 7.Quartz glass is acidic materials, except hydro fluoric acid and 300 degrees Celsius thermal phosphoric acid, on any other acids were shown to be inert, is the best anti acid materials. The advantages of Customized High Quality
Tidak Ada Gelembung Udara Pelat Kaca Datar Kemurnian Tinggi Kaca Kuarsa Jendela Transparan Kacamata Sight Edaran
No Air Bubble Flat Glass Plates Excellent Visual Performance Circular Shape Quartz Glass Window Product description: Fused clear silica quartz glass plate is made of high purity quartz sand with excellent thermal shock stability and high transmittance. It is widely used in electric light/ laser/ lenses/optical instrument/high temperature window. Application of quartz plate: Military industrial complex, machinery, metallurgy, printing and dyeing, optical instruments, high
break
Product description: Fused clear silica quartz glass plate is made of high purity quartz sand with excellent thermal shock stability and high transmittance. It is widely used in electric light/ laser/ lenses/optical instrument/high temperature window. Application of quartz plate: Military industrial complex, machinery, metallurgy, printing and dyeing, optical instruments, high temperature sight glasses, fire hole industries such as high temperature and other industries,
Silakan gunakan formulir kontak pertanyaan online kami di bawah ini jika Anda memiliki pertanyaan, tim kami akan menghubungi Anda sesegera mungkin.
