Tahan Suhu Tinggi Sangat Transparan 92% Plat Kaca Kuarsa untuk Aplikasi Lampu UV
Detail Produk
| Jenis: | Pelat kuarsa yang jelas | Aplikasi: | Semikonduktor, optik |
|---|---|---|---|
| Ketebalan: | 0,5-100mm | Membentuk: | Bulat |
| Layanan Pemrosesan: | Meninju, memotong | Nama Produk: | Pelat Kaca Kuarsa |
| Bahan: | SiO2 | SiO2: | SiO2> 99,99% |
| Kepadatan: | 2.2g/cm3 | Warna: | Bening Transparan |
| Suhu Kerja: | 1100 ℃ | Titik lebur: | 1732℃ |
| Pelabuhan: | Port Shanghai dan Qindao | ||
| Menyoroti |
Lembar kaca Kuarsa tahan suhu tinggi,pelat kaca kuarsa yang sangat transparan,Lapisan kaca kuarsa untuk lampu UV |
||
Deskripsi Produk
|
Karakteristik pelat Shengfan Quartz
|
|
|
|
*merek
|
Shengfanquartz
|
|
|
*SIO2
|
99.99%
|
|
|
*Kepadatan
|
2.2 ((g/cm3)
|
|
|
* Tingkat kekerasan skala moh
|
6.6
|
|
|
* Titik leleh
|
1732°C
|
|
|
* Suhu kerja
|
1100°C
|
|
|
* Titik penggilingan
|
1180°C
|
|
|
* Titik melembutkan
|
1630°C
|
|
| Kepadatan | 2.2x103 kg/m3 | Kekerasan | 5.5 - 6.5 Skala Mohs 570 KHN 100 |
| Desain Kekuatan Tarikan | 4.8x107 Pa (N/m2) (7000 psi) | Desain Kekuatan Kompresi | Lebih dari 1,1 x l09 Pa (160.000 psi) SMD 5730 |
| Bulk Modulus | 3.7x1010 Pa (5.3x106 psi) | Modulus kekakuan | 3.1x1010 Pa (4.5x106 psi) |
| Titik Perlahan | 1730°C | Titik Annealing | 1215°C |
|
Pengaturan Informasi
|
|
|
|
Warna
|
Transparan
|
|
|
Bentuk
|
Bulat / Bulat
|
|
|
Standar
|
JGS1, JGS2, JGS3
|
|
|
Bahan
|
99.99% SiO2
|
|
|
Diameter
|
1-800mm
|
|
|
Ketebalan
|
0.2-100mm
|
|
|
Aplikasi
|
Jendela optik kuarsa
|
|
|
Kepadatan
|
6.6
|
|
|
Transmisi cahaya
|
> 92%
|
|
|
Kekerasan
|
Mose 6.5
|
|
|
Nilai resistensi
|
1000 kali dari kaca biasa
|
|
Layanan kami & KekuatanPerusahaan mematuhi integritas bisnis, pengalaman, harga yang wajar, jaminan kualitas, untuk memberikan layanan purna jual yang sangat baik,Kami dengan tulus menyambut pelanggan untuk datang untuk bernegosiasi
