Kemurnian Tinggi SIO2 99,99% Tahan panas hingga 1200°C Tabung Kaca Kuarsa Tembaga Transparan untuk Aplikasi Semikonduktor dan Optik
Detail Produk
| Jenis: | Tabung kuarsa bening | Aplikasi: | Semikonduktor, optik |
|---|---|---|---|
| Ketebalan: | 1-100mm | Membentuk: | Bulat |
| Layanan Pemrosesan: | Meninju, memotong | Nama Produk: | Tabung uji kuarsa |
| Bahan: | SiO2 | SiO2: | SiO2> 99,99% |
| Kepadatan: | 2.2g/cm3 | Warna: | Bening Transparan |
| Suhu Kerja: | 1100 ℃ | Titik lebur: | 1732℃ |
| Pelabuhan: | Port Shanghai dan Qindao | ||
| Menyoroti |
tabung kuarsa cair kemurnian tinggi,Tabung kaca tungku SIO2,kaca kuarsa tahan panas |
||
Deskripsi Produk
|
Karakteristik tabung kuarsa Shengfan
|
|
|
|
*Merek
|
shengfanquartz
|
|
|
*SIO2
|
99,99%
|
|
|
*Kepadatan
|
2,2(g/cm³)
|
|
|
*Tingkat kekerasan skala moh
|
6,6
|
|
|
*Titik lebur
|
1732°C
|
|
|
* Suhu kerja
|
1100°C
|
|
|
*Titik anil
|
1180°C
|
|
|
*Titik pelunakan
|
1630°C
|
|
| Kepadatan | 2,2x103 kg/m3 | Kekerasan | 5,5 - 6,5 Skala Mohs 570 KHN 100 |
| Kekuatan Tarik Desain | 4,8x107 Pa (N/m2) (7000 psi) | Kekuatan Kompresi Desain | Lebih besar dari 1,1 x l09 Pa (160.000 psi)SMD 5730 |
| Modulus Curah | 3,7x1010 Pa (5,3x106 psi) | Modulus Kekakuan | 3,1x1010 Pa (4,5x106 psi) |
| Titik Pelunakan | 1730°C | Titik Anil | 1215°C |
|
Informasi Pengaturan
|
|
|
|
Warna
|
Transparan
|
|
|
Bentuk
|
Lingkaran / Bulat
|
|
|
Standar
|
JGS1
|
|
|
Bahan
|
99,99% sio2
|
|
|
Diameter
|
1-800mm
|
|
|
Ketebalan
|
0,25-10mm
|
|
|
Aplikasi
|
Jendela kuarsa optik
|
|
|
Kepadatan
|
6,6
|
|
|
Transmisi Cahaya
|
>92%
|
|
|
Kekerasan
|
Mose 6,5
|
|
|
Nilai Resistansi
|
1000 kali lebih baik dari kaca biasa
|
|
kemasan
